ALC10A471EH500

470uF ±20% 500V 3.56A100Hz Φ40mm

470 µF 500 V 铝电解器 径向，Can - 卡入式 285 毫欧 @ 100Hz 85°C 时为 18000 小时

得捷:
CAP ALUM 470UF 20% 500V SNAP

立创商城:
470uF ±20% 500V

贸泽:
Aluminum Electrolytic Capacitors - Snap In 470uF 500VDC 20%

艾睿:
Do you need something that can let through high frequencies and filter out low frequencies? The electrolytic ALC10A471EH500 electrolytic capacitor from Kemet is for you. It can withstand a voltage of 500 VDC. This aluminum electrolytic capacitor has a maximum operating temperature of 85 °C. This product is 60 mm tall with a diameter of 40 mm. Its leakage current is 1410@5Min μA. It has a tolerance of 20%. Its capacitance value is 470uF. The ALC10A471EH500 aluminum electrolytic capacitor has a snap-in termination style.

Allied Electronics:
Capacitor; Al Electrolytic; Cap 470 uF; Tol 20%; Vol-Rtg 500 VDC; Snap-In; 40X60 mm

Verical:
Cap Aluminum Lytic 470uF 500V 20% 40 X 60mm Snap-In 0.285 Ohm 3560mA 18000h 85C Bulk
