AC-DC Power Supply Single-OUT 24V 17.5A 24Pin
开放框架 AC DC 转换器 1 输出 24V - - - 25A 90 ~ 277 VAC 输入
得捷:
AC/DC CONVERTER 24V 420W
艾睿:
Safely convert alternating currents into direct currents that your electronic devices can make use of with this ABC600-1024G AC to DC power supply from Bel Power Solutions. It has a voltage of Single V and maximum output power of 6@Ta=50C W. This part&s;s 600 outputs can handle a current up to 420 A. This part has a temperature range of -50 °C to 150 °C. This product comes packaged in bulk, so the parts will be stored loosely.
Verical:
AC/DC Power Supply Single-OUT 24V 17.5A 23-Pin
MASTER:
AC/DC Power Supply Single-OUT 24V 17.5A
Online Components:
AC/DC Power Supply Single-OUT 24V 17.5A 24-Pin
Electro Sonic:
AC/DC Power Supply Single-OUT 24V 17.5A
输出接口数 1
输出电压 24 V
输出电流 17.5 A
隔离电压 4.242 kV
输入电压DC Max 390 V
输入电压DC Min 120 V
输入电压AC Max 277 V
输入电压AC Min 90 V
输出电流Max 17.5 A
输入电流Min 9 Arms
输出功率Max 420 W
工作温度Max 70 ℃
工作温度Min -25 ℃
输入电压 90VAC ~ 277VAC
引脚数 23
长度 203.2 mm
宽度 127 mm
高度 40.64 mm
工作温度 -25℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
