1 A,低压差, CMOS线性稳压器 1 A, Low Dropout, CMOS Linear Regulator
PMIC - 稳压器 - 线性 正 固定 1 输出 1A 8-SOIC-EP
得捷:
IC REG LINEAR 2.5V 1A 8SOIC
立创商城:
ADP1707ARDZ-2.5-R7
艾睿:
Never worry about components not turning off and on due to lack of voltage with this LDO ADP1707ARDZ-2.5-R7 linear regulator from Analog Devices. Its typical dropout voltage at current is 0.035@100mA|0.365@1A V. It has an overall accuracy of ±1.5 %. This voltage regulation device&s;s single output can produce a current up to 1 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.5 V and no higher than 5.5 V. With a fixed output that has a voltage of 2.5 V, this is power management at its best. At a load regulation of 0.001%/mA and line regulation of 0.1%/V your circuit is capable of maintaining a constant voltage level at your output. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive. The maximum dropout voltage is 0.06@100mA|0.63@1A V.
Chip1Stop:
LDO Regulator Pos 2.5V 1A 8-Pin SOIC N EP T/R
Verical:
LDO Regulator Pos 2.5V 1A 8-Pin SOIC N EP T/R
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 2.5V 1A 8-SOIC-EP
输出接口数 1
输出电压 2.5 V
输出电流 1 A
供电电流 1.55 mA
跌落电压 0.365V @1A
输入电压Max 5.5 V
输入电压Min 2.5 V
输出电压Min 2.5 V
输出电流Max 1 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±1.5 %
输入电压 ≤5.5 V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
军工级 No
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ADP1707ARDZ-2.5-R7 ADI 亚德诺 | 当前型号 | 当前型号 |
ADP1706ARDZ-2.5-R7 亚德诺 | 类似代替 | ADP1707ARDZ-2.5-R7和ADP1706ARDZ-2.5-R7的区别 |
