Analog Devices### 开关电压调节器,Analog DevicesAnalog Devices 各种开关调节器在升压(增压)、降压(下降)和反相电压模式下操作。 调节器可产生固定或可调输出电压。
升压开关稳压器,Analog Devices
欧时:
升压开关稳压器,Analog Devices### 开关稳压器,Analog DevicesAnalog Devices 各种开关稳压器在升压(增压)、降压(下降)和反相电压模式下操作。 调节器可产生固定或可调输出电压。
得捷:
IC REG BOOST ADJ 1.2A 8MSOP
立创商城:
升压型 Vin=2.5V~5.5V Vout=2.5V~12V 1.2A
艾睿:
Adjust the voltage level of your devices with this step up ADP1610ARMZ-R7 DC to DC converter from Analog Devices. This converter&s;s single output can produce a current up to 2Typ A. By only needing an input voltage of 2.5 V with a maximum of 5.5 V, this is the best way to control the power in your circuit. With an adjustable output that has a voltage of 2.5 to 12 V, this is power management at its best. This converter is 92 % efficient. To produce a constant current at your output, supply your circuit with a load regulation of 0.05mV/VTyp and line regulation of 0.15%/V. You can operate this at a switching frequency of 885|1600 kHz. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This converter has an operating temperature range of -40 °C to 85 °C.
安富利:
Conv DC-DC Single Step Up 2.5V to 5.5V 8-Pin MSOP T/R
Chip1Stop:
Conv DC-DC Single Step Up 2.5V to 5.5V 8-Pin MSOP T/R
Verical:
Conv DC-DC 2.5V to 5.5V Step Up Single-Out 2.5V to 12V 2A 8-Pin MSOP T/R
Newark:
# ANALOG DEVICES ADP1610ARMZ-R7 DC-DC Switching Boost, Regulator, Adjustable, 2.5V-5.5Vin, 3.3V-12Vout, 1.2Aout, MSOP-8
DeviceMart:
IC REG BOOST ADJ 1.2A 8MSOP
Win Source:
Boost Switching Regulator IC Positive Adjustable 2.5V 1 Output 1.2A Switch 8-TSSOP, 8-MSOP 0.118", 3.00mm Width
输出接口数 1
输出电压 2.5V ~ 12V
输出电流 1.2 A
供电电流 600 µA
开关频率 700kHz, 1.23MHz
输入电压Max 5.5 V
输入电压Min 2.5 V
输出电压Max 12 V
输出电压Min 2.5 V
输出电流Max 1.2 A
工作温度Max 85 ℃
工作温度Min -40 ℃
精度 3 %
电源电压 2.5 V
电源电压Max 5.5 V
电源电压Min 2.5 V
输入电压 2.5V ~ 5.5V
安装方式 Surface Mount
引脚数 8
封装 MSOP-8
长度 3.2 mm
宽度 3.2 mm
高度 0.95 mm
封装 MSOP-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
ADP1610ARMZ-R7 ADI 亚德诺 | 当前型号 | 当前型号 |
ADP1611ARMZ-R7 亚德诺 | 功能相似 | ADP1610ARMZ-R7和ADP1611ARMZ-R7的区别 |
