3.2 x 2.4 x 2.4 mm 20° 水色透明 3000 mcd 3.3 V 片式 LED 灯 表面贴装
绿色 525nm 指示 - 分立 3.3V 1210(3225 公制)
得捷:
LED GREEN CLEAR SMD
贸泽:
Standard LEDs - SMD Green Water Clear 525nm 2400mcd
艾睿:
LED Uni-Color Green 515nm 2-Pin Chip LED T/R
Allied Electronics:
APD3224ZGC-F01 Green LED, 525 nm Chip LED Clear, Dome Lens SMD package
安富利:
LED Uni-Color Green 515nm Chip LED 2-Pin SMD T/R
富昌:
绿色 3.2 x 2.4 x 2.4 mm 20° 水色透明 3000 mcd 3.3 V 片式 LED 灯 表面贴装
Chip1Stop:
LED Uni-Color Green 515nm 2-Pin SMD T/R
Win Source:
LED GREEN CLEAR SMD / Green 525nm LED Indication - Discrete 3.3V 1210 3225 Metric
工作电压 3.3 V
正向电压 3.3 V
波长 525 nm
发光强度 2400 mcd
视角 20°
峰值波长 515 nm
耗散功率 102.5 mW
测试电流 20 mA
正向电流 25 mA
正向电压Max 4.1 V
正向电流Max 25 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 102.5 mW
安装方式 Surface Mount
引脚数 2
封装公制 3225
封装 1210
长度 3.2 mm
宽度 2.4 mm
高度 2.40 mm
封装公制 3225
封装 1210
颜色 Green
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
