A4984SESTR-T

集成电路/电机驱动芯片

Description

The A4984 is a complete microstepping motor driver with built-in translator for easy operation. It is designed to operate bipolar stepper motors in full-, half-, quarter-, and eighth-step modes. Step modes are selectable by MSx logic inputs. It has an output drive capacity of up to 35 V and ±2 A. The A4984 includes a fixed off-time current regulator which has the ability to operate in Slow or Mixed decay modes.

Features and Benefits

▪ Low RDSON outputs

▪ Automatic current decay mode detection/selection

▪ Mixed and Slow current decay modes

▪ Synchronous rectification for low power dissipation

▪ Internal UVLO

▪ Crossover-current protection

▪ 3.3 and 5 V compatible logic supply

▪ Thin profile QFN and TSSOP packages

▪ Thermal shutdown circuitry

▪ Short-to-ground protection

▪ Shorted load protection

▪ Low current Sleep mode, < 10 μA

▪ No smoke no fire NSNF compliance ET package
