窄间距连接器（ 0.5mm间距）自动安装 Narrow pitch connectors 0.5mm pitch Automatic mounting
20 Position Connector Header, Outer Shroud Contacts Surface Mount Gold
得捷:
CONN HDR 20POS SMD GOLD
欧时:
Connector, P5KS, Header, 0.50mm pitch, 2
艾睿:
Conn Board to Board HDR 20 POS 0.5mm Solder ST SMD Reel
安富利:
Conn Board to Board HDR 20 POS 0.5mm Solder ST SMD Embossed T/R
Verical:
Conn Board to Board PL 20 POS 0.5mm Solder ST SMD Reel
MASTER:
Conn Board to Board HDR 20 POS 0.5mm Solder ST SMD Reel
Electro Sonic:
Conn Board to Board HDR 20 POS 0.5mm Solder ST SMD Reel
触点数 20
额定电流 0.5 A
绝缘电阻 1000 MΩ
排数 2
针脚数 20
拔插次数 50
额定电流Max 16 A
工作温度Max 85 ℃
工作温度Min -55 ℃
额定电压 60 V
接触电阻Max 80 mΩ
安装方式 Surface Mount
引脚数 20
高度 5.3 mm
触点材质 Copper Alloy
工作温度 -55℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536694040
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
AXK6S20647YG Panasonic 松下 | 当前型号 | 当前型号 |
AXK6S20647YA 松下 | 完全替代 | AXK6S20647YG和AXK6S20647YA的区别 |
