1200 MHz至2500 MHz的平衡混频器， LO缓冲器， IF放大器和RF巴伦 1200 MHz to 2500 MHz Balanced Mixer, LO Buffer, IF Amplifier, and RF Balun
GENERAL DESCRIPTION
The ADL5355 uses a highly linear, doubly balanced passive mixer core along with integrated RF and LO balancing circuitry to allow for single-ended operation.
FEATURES
RF frequency range of 1200 MHz to 2500 MHz
IF frequency range of 30 MHz to 450 MHz
Power conversion gain: 8.4 dB
SSB noise figure of 9.2 dB
SSB noise figure with 5 dBm blocker of 20 dB
Input IP3 of 27 dBm
Input P1dB of 10.4 dBm
Typical LO drive of 0 dBm
Single-ended, 50 Ω RF and LO input ports
High isolation SPDT LO input switch
Single-supply operation: 3.3 V to 5 V
Exposed paddle 5 mm × 5 mm, 20-lead LFCSP
1500 V HBM/500 V FICDM ESD performance
APPLICATIONS
Cellular base station receivers
Transmit observation receivers
Radio link downconverters
