0402 470R 5%汽车级
SMD器/芯片电阻器
欧时:
Resistor AEC-Q200 Thick film 0402 5% 470
得捷:
RES SMD 470 OHM 5% 1/16W 0402
立创商城:
470Ω ±5% 62.5mW
艾睿:
This is a AC0402JR-07470RL fixed single surface-mount resistor from Yageo. This product has a resistance value of 470 Ohm. This dependable part has a power rating of 0.063 1/16 W. Its temperature coefficient is ±100 ppm/°C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This part has an operating temperature of -55 to 155 °C. This device utilizes thick film technology. It has a tolerance of 5%. This product is 1 mm long, 0.32 mm tall and 0.5 mm deep.
安富利:
YAGAC0402JR-07470RL
儒卓力:
**AC0402 470R 5% 0,063W AUTOMO **
容差 ±5 %
额定功率 0.063 W
产品系列 AC
电阻 470 Ω
阻值偏差 ±5 %
工作温度Max 155 ℃
工作温度Min -55 ℃
精度 ±5 %
安装方式 Surface Mount
封装公制 1005
封装 0402
长度 1 mm
宽度 0.5 mm
高度 0.32 mm
封装公制 1005
封装 0402
工作温度 -55℃ ~ 155℃
温度系数 ±100 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 10000
RoHS标准 Non-Compliant
含铅标准 Lead Free
ECCN代码 EAR99
