ADA4000-2ARZ-R7

低成本，精密JFET输入运算放大器 Low Cost, Precision JFET Input Operational Amplifiers

Product Details

The ADA4000-1 / ADA4000-2 / ADA4000-4 are junction field effect transistor JFET input operational amplifiers featuring precision, very low bias current, and low power. Combining high input impedance, low input bias current, wide bandwidth, fast slew rate, and fast settling time, the ADA4000-1 / ADA4000-2 / ADA4000-4 are ideal amplifiers for driving analog-to-digital inputs and buffering digital-to-analog converter outputs. The input common-mode voltage includes the positive power supply, which makes the device an excellent choice for high-side signal conditioning.

Additional applications for the ADA4000-1 / ADA4000-2 / ADA4000-4 include electronic instruments, automated test equipment ATE amplification, buffering, integrator circuits, instrumentation-quality photodiode amplification, and fast precision filters including phase-locked loop filters. The devices also include utility functions, such as reference buffering, level shifting, control input/output interface, power supply control, and monitoring functions.

Applications

.

Reference gain/buffers

.

Level shift/driving

.

Active filters

.

Power line monitoring/control

.

Current/voltage sense or monitoring

.

Data acquisition

.

Sample-and-hold circuits

.

Integrators

### Features and Benefits

.

High slew rate: 20 V/μs

.

Fast settling time

.

Low offset voltage: 1.70 mV maximum

.

Bias current: 40 pA maximum

.

±4 V to ±18 V operation

.

Low voltage noise: 16 nV/√Hz

.

Unity gain stable

.

Common-mode voltage includes +VS

.

Wide bandwidth: 5 MHz
