AD8203YRMZ-R7

高共模电压，单电源差动放大器 High Common-Mode Voltage, Single-Supply Difference Amplifier

Product Details

The AD8203 is a single-supply difference amplifier for amplifying and low-pass filtering small differential voltages in the presence of a large common-mode voltage CMV. The input CMV range extends from -6 V to +30 V at a typical supply voltage of 5 V.

The AD8203 is available in die and packaged form. The MSOP and SOIC packages are specified over a wide temperature range, from -40°C to +125°C, while the die is specified over a wider temperature range, from -40°C to +150°C, making the AD8203 well-suited for use in many automotive platforms.

### Features and Benefits

.

High common-mode voltage range -6 V to

+30 V at a 5 V supply voltage

.

Operating temperature range -40°C to +125°C

.

Supply voltage range: 3.5 V to 12 V

.

Low-pass filter 1-pole or 2-pole

.

Excellent ac and dc performance

±1 mV voltage offset 8-lead SOIC

±1 ppm/°C typical gain drift

80 dB CMRR minimum dc to 10 kHz
