ADA4857-1YRZ-R7

超低失真，低功耗，低噪声，高速运算放大器 Ultralow Distortion, Low Power, Low Noise, High Speed Op Amp

Product Details

The ADA4857 is a unity gain stable, high speed, voltage feedback amplifier with low distortion, low noise, and high slew rate. With a spurious-free dynamic range SFDR of −88 dBc @ 10 MHz, the ADA4857 is an ideal solution for a variety of applications including ultrasounds, ATE, active filters, and ADC drivers. The Analog Devices, Inc., proprietary next-generation XFCB process and innovative architecture enables such high performance amplifiers.

The ADA4857 has 850 MHz bandwidth, 2800 V/μs slew rate, and settles to 0.1% in 15 ns. With a wide supply voltage range 5 V to 10 V, the ADA4857 is an ideal candidate for systems that require high dynamic range, precision, and speed.

The ADA4857-1 amplifier is available in a 3 mm × 3 mm, 8-lead LFCSP and a standard 8-lead SOIC. The ADA4857-2 is available in a 4 mm × 4 mm, 16-lead LFSCP. The LFCSP features an exposed paddle that provides a low thermal resistance path to the printed circuit board PCB. This path enables more efficient heat transfer and increases reliability. The ADA4857 works over the extended industrial temperature range −40°C to +125°C.

**Applications**

.

Instrumentation

.

IF and baseband amplifiers

.

Active filters

.

ADC drivers

.

DAC buffers

### Features and Benefits

.

High speed

850 MHz, -3 dB bandwidth G = +1, RL = 1kΩ, LFSCP

750 MHz, −3 dB bandwidth G = +1, RL = 1 kΩ, SOIC

2800 V/µs slew rate

.

Low distortion:

-88 dBc @ 10 MHz G = +1, RL = 1kΩ

.

Low power: 5 mA/amplifier @ 10 V

.

Low noise: 4.4 nV/√Hz

.

Wide supply voltage range: 5 V to 10 V

.

Power-down feature

.

Available in 3 mm × 3 mm 8-lead LFCSP single, 8-lead SOIC single, and 4 mm × 4 mm 16-lead LFCSP dual
