高性能, 145 MHz的FastFET⑩运算放大器 High Performance, 145 MHz FastFET⑩ Op Amps
电压反馈 放大器 电路 满摆幅 8-SOIC
得捷:
IC VOLTAGE FEEDBACK 1 CIRC 8SOIC
立创商城:
AD8065ARZ-REEL
贸泽:
运算放大器 - 运放 SOIC Hi Perf Hi Spd FET Amp w/ Disable
艾睿:
The large amount of gain, or amplification, produced by this voltage feedback amplifier AD8065ARZ-REEL OP amp from Analog Devices make it a commonly used component in nearly all electronics today. Its typical dual supply voltage is ±3|±5|±9 V, with a minimum of ±2.5 V and maximum of ±12 V. This op amp has a minimum operating temperature of -40 °C and a maximum of 85 °C. It has a single channel per chip. This device uses one or two power supplies. This device is made with bifet technology.
安富利:
OP Amp Single Volt Fdbk R-R O/P ±12V/24V 8-Pin SOIC N T/R
供电电流 6.6 mA
电路数 1
通道数 1
共模抑制比 100 dB
输入电容 2.10 pF
转换速率 180 V/μs
增益频宽积 145 MHz
输入阻抗 1.00 TΩ
输入补偿电压 400 µV
输入偏置电流 3 pA
工作温度Max 85 ℃
工作温度Min -40 ℃
3dB带宽 145 MHz
共模抑制比Min 74 dB
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
军工级 No
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AD8065ARZ-REEL ADI 亚德诺 | 当前型号 | 当前型号 |
AD8065ARZ-REEL7 亚德诺 | 完全替代 | AD8065ARZ-REEL和AD8065ARZ-REEL7的区别 |
AD8065AR-REEL7 亚德诺 | 完全替代 | AD8065ARZ-REEL和AD8065AR-REEL7的区别 |
AD8065AR-REEL 亚德诺 | 完全替代 | AD8065ARZ-REEL和AD8065AR-REEL的区别 |
