Analog Devices### 运算放大器,Analog Devices
单电源 JFET 运算放大器,Analog Devices
一系列 Analog Devices 的 JFET 输入运算放大器适用于由单轨电源供电操作。这些运算放大器的输入共模范围包括接地(或具有双电源的负电源轨),大多数器件具有轨到轨输出。提供单、双和四路封装选项。
立创商城:
放大器
得捷:
IC OPAMP GP 2 CIRCUIT 8SOIC
欧时:
### 双精密运算放大器,Analog Devices### 运算放大器,Analog Devices
贸泽:
Precision Amplifiers SGL-Supply RR Lo Pwr FET-Inpt Dual
艾睿:
Increase functionality to your instrumentation with this general purpose amplifier AD822BRZ-REEL7 OP amp from Analog Devices. Its typical dual supply voltage is ±3|±5|±9|±12 V, with a minimum of ±2.5 V and maximum of ±15 V. This op amp has a temperature range of -40 °C to 85 °C. This device utilizes bifet technology. It has 2 channels per chip. This device uses one or two power supplies.
Verical:
Op Amp Dual Low Power Amplifier R-R O/P ±15V/30V 8-Pin SOIC N T/R
Win Source:
IC OPAMP GP 1.9MHZ RRO 8SOIC
供电电流 1.4 mA
电路数 2
通道数 2
共模抑制比 80 dB
输入电容 2.80 pF
转换速率 3.00 V/μs
增益频宽积 1.8 MHz
输入阻抗 10.0 TΩ
输入补偿电压 300 µV
输入偏置电流 2 pA
工作温度Max 85 ℃
工作温度Min -40 ℃
3dB带宽 1.9 MHz
增益带宽 1.9 MHz
共模抑制比Min 69 dB
电源电压Max 30 V
电源电压Min 5 V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
长度 5 mm
宽度 4 mm
高度 1.5 mm
封装 SOIC-8
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Wearable Health Monitoring, Healthcare, Clinical Monitoring, Life Sciences & Medical Instrumentation, Imaging, Digital X-Ray, CT-Imaging, NiBP based on ECG and PPG, Health, Wellness and Fitness, ECG Patient Monitoring, Spectrometer, Sport Watch
RoHS标准 RoHS Compliant
含铅标准 Contains Lead
军工级 No
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AD822BRZ-REEL7 ADI 亚德诺 | 当前型号 | 当前型号 |
AD822ARZ 亚德诺 | 类似代替 | AD822BRZ-REEL7和AD822ARZ的区别 |
AD822BRZ 亚德诺 | 类似代替 | AD822BRZ-REEL7和AD822BRZ的区别 |
AD822ARZ-REEL7 亚德诺 | 类似代替 | AD822BRZ-REEL7和AD822ARZ-REEL7的区别 |
