AD8625ARZ-REEL

精密低功耗单电源JFET放大器 Precision Low Power Single-Supply JFET Amplifiers

GENERAL DESCRIPTION

The AD862x is a precision JFET input amplifier. It features true single-supply operation, low power consumption, and rail-to-rail output. The outputs remain stable with capacitive loads of over 500 pF; the supply current is less than 630 μA/amp. Applications for the AD862x include photodiode transimpedance amplification, ATE reference level drivers, battery management, both line powered and portable instrumentation, and remote sensor signal conditioning, which includes automotive sensors.

FEATURES

SC70 package

Very low IB: 1 pA max

Single-supply operation: 5 V to 26 V

Dual-supply operation: ±2.5 V to ±13 V

Rail-to-rail output

Low supply current: 630 μA/amp typ

Low offset voltage: 500 μV max

Unity gain stable

No phase reversal

APPLICATIONS

Photodiode amplifiers

ATEs

Line-powered/battery-powered instrumentation

Industrial controls

Automotive sensors

Precision filters

Audio
