1 MHz至1.2 GHz的VGA 30 dB增益控制范围 1 MHz to 1.2 GHz VGA with 30 dB Gain Control Range
射频放大器 IC CATV 1MHz ~ 1.2GHz 24-LFCSP-VQ(4x4)
得捷:
IC AMP CATV 1MHZ-1.2GHZ 24LFCSP
立创商城:
ADL5331ACPZ-R7
贸泽:
差分放大器 Broadband Differential VGA
艾睿:
Make your RF signal stand out against noise by using this gain amplifier ADL5331ACPZ-R7 buffer amplifier from Analog Devices. Its maximum power dissipation is 1200 mW. This RF amplifier chip has a minimum operating temperature of -40 °C and a maximum of 85 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. It has a single channel per chip. This device uses a single power supply.
安富利:
RF Amp Chip Single Gain Amp 1.2GHz 5.25V 24-Pin LFCSP EP T/R
Verical:
RF Amp Chip Single Gain Amp 1.2GHz 5.25V 24-Pin LFCSP EP T/R
罗切斯特:
1 MHz to 1.2 GHz VGA with 30DB Gain Control Range
Win Source:
RF Amplifier IC CATV 1MHz ~ 1.2GHz 24-LFCSP-VQ 4x4
DeviceMart:
BROADBAND DIFFERENTIAL VGA
频率 1MHz ~ 1.2GHz
供电电流 240 mA
通道数 1
耗散功率 1.2 W
增益 15 dB
测试频率 900 MHz
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 1200 mW
电源电压 4.75V ~ 5.25V
安装方式 Surface Mount
引脚数 24
封装 LFCSP-24
长度 4 mm
宽度 4 mm
高度 0.83 mm
封装 LFCSP-24
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
