AISC-0402-11NJ-T

11nH ±5% 编带

11nH Unshielded Wirewound Inductor 640mA 120mOhm Max 0402 1005 Metric

得捷:
FIXED IND 11NH 640MA 120MOHM SMD

立创商城:
11nH ±5%

艾睿:
Save valuable space on a PCB with this chip AISC-0402-11NJT surface mount inductor from Abracon Corporation. This SMD inductor has a minimum operating temperature of -40 °C and a maximum of 125 °C. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This product is 1.19 mm long, 0.66 mm tall and 0.64 mm deep. Its test frequency is 250M Hz, while its minimum self-resonant frequency is 3.68G Hz. This SMD inductor has a maximum DC current of 640m A with a maximum resistance of 120m Ohm. It has a tolerance of 5%. It has an inductance of 11n H. This device is made with wirewound technology.

Verical:
Inductor RF Wirewound 0.011uH 5% 250MHz 26Q-Factor Ceramic 0.64A 0.12Ohm DCR 0402 T/R
