AD8608AR

精密，低噪声， CMOS ，轨到轨输入/输出运算放大器 Precision, Low Noise, CMOS, Rail-to-Rail, Input/Output Operational Amplifiers

GENERAL DESCRIPTION

The AD8605, AD8606, and AD86081 are single, dual, and quad rail-to-rail input and output, single-supply amplifiers. They feature very low offset voltage, low input voltage and current noise, and wide signal bandwidth. They use the Analog Devices, Inc. patented DigiTrim® trimming technique, which achieves superior precision without laser trimming.

FEATURES

Low offset voltage: 65 μV maximum

Low input bias currents: 1 pA maximum

Low noise: 8 nV/√Hz

Wide bandwidth: 10 MHZ

High open-loop gain: 1000 V/mV

Unity gain stable

Single-supply operation: 2.7 V to 5.5 V

5-ball WLCSP for single AD8605 and 8-ball WLCSP for dual AD8606

APPLICATIONS

Photodiode amplification

Battery-powered instrumentation

Multipole filters

Sensors

Barcode scanners

Audio
