ADF4360-8BCPZRL7

Clock Generator 10MHz to 250MHz Input 400MHz Output 24Pin LFCSP EP T/R

Product Details

The ADF4360-8 is an integrated integer-N synthesizer and voltage controlled oscillator VCO. The ADF4360-8 center frequency is set by external inductors. This allows a frequency range of between 65 MHz to 400 MHz. Control of all the on-chip registers is through a simple 3-wire interface. The device operates with a power supply ranging from 3.0 V to 3.6 V and can be powered down when not in use.

### Features and Benefits

.

Output frequency range: 65 MHz to 400 MHz

.

3.0 V to 3.6 V power supply

.

1.8 V logic compatibility

.

Integer-N synthesizer

.

Programmable output power level

.

3-wire serial interface

.

Digital lock detect

.

Hardware and software power-down mode
