数模转换器- DAC 10-Bit, 40 MSPS Dual DAC
10 位 2 28-SSOP
得捷:
IC DAC 10BIT A-OUT 28SSOP
立创商城:
AD9761ARSZRL
贸泽:
数模转换器- DAC 10-Bit, 40 MSPS Dual DAC
艾睿:
Need to convert your digital signals to analog? This AD9761ARSZRL DAC converter from Analog Devices is the one you want. This device is based on Segment architecture. This device&s;s digital interface is parallel. It has a current output. This DAC has a resolution of 10bit. This DAC has a temperature range of -40 °C to 85 °C. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This device uses analog and digital power.
安富利:
DAC 2-CH Segment 10-bit 28-Pin SSOP T/R
Chip1Stop:
DAC 2-CH Segment 10-bit 28-Pin SSOP T/R
Verical:
DAC 2-CH Segment 10-bit 28-Pin SSOP T/R
罗切斯特:
D/A Converter, 2 Func, Parallel, Word Input Loading, 0.035us Settling Time, PDSO28
输出接口数 2
通道数 2
位数 10
耗散功率 0.25 W
采样率 40 Msps
分辨率Bits 10.0
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 250 mW
数模转换数DAC 2
电源电压Max 5.5 V
电源电压Min 2.7 V
安装方式 Surface Mount
引脚数 28
封装 SSOP-28
高度 1.75 mm
封装 SSOP-28
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
军工级 No
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AD9761ARSZRL ADI 亚德诺 | 当前型号 | 当前型号 |
AD9761ARSZ 亚德诺 | 类似代替 | AD9761ARSZRL和AD9761ARSZ的区别 |
AD9761ARS 亚德诺 | 类似代替 | AD9761ARSZRL和AD9761ARS的区别 |
AD9761ARSRL 亚德诺 | 类似代替 | AD9761ARSZRL和AD9761ARSRL的区别 |
