300毫安,低压降CMOS线性稳压器 300 mA, Low Dropout CMOS Linear Regulator
PMIC - 稳压器 - 线性 正 固定 1 输出 300mA TSOT-23-5
得捷:
IC REG LINEAR 1V 300MA TSOT5
立创商城:
ADP1713AUJZ-1.0-R7
艾睿:
Having trouble maintaining a steady voltage? This LDO ADP1713AUJZ-1.0-R7 linear regulator from Analog Devices will give you control over the voltage levels of your circuit. Its typical dropout voltage at current is 0.17@300mA V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s single output can produce a current up to 0.3 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.5 V that does not exceed 5.5 V. With a fixed output that has a voltage of 1 V, this is power management at its best. A load regulation of 0.001%/mATyp and line regulation of 0.25%/V is necessary for providing a constant voltage level at your output. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.
输出接口数 1
输出电压 1 V
输出电流 300 mA
供电电流 70µA ~ 420µA
跌落电压 0.17V @300mA
输入电压Max 5.5 V
输入电压Min 2.5 V
输出电压Min 1 V
输出电流Max 0.3 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±1 %
输入电压 2.5V ~ 5.5V
安装方式 Surface Mount
引脚数 5
封装 TSOT-23-5
封装 TSOT-23-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
军工级 No
