AD8651ARMZ

ANALOG DEVICES  AD8651ARMZ  运算放大器, 单路, 50 MHz, 1个放大器, 41 V/µs, 2.7V 至 5.5V, MSOP, 8 引脚

CMOS 精密，Analog Devices

得捷:
IC VOLTAGE FEEDBACK 1 CIRC 8MSOP

欧时:
OP Amp Single GP R-R I/O 5.5V 8-Pin MSOP

立创商城:
AD8651ARMZ

e络盟:
运算放大器, 单路, 50 MHz, 1个放大器, 41 V/µs, 2.7V 至 5.5V, MSOP, 8 引脚

艾睿:
Op Amp Single Low Noise Amplifier R-R I/O 5.5V 8-Pin MSOP Tube

安富利:
The AD865x family consists of high precision, low noise, low distortion, rail-to-rail CMOS operational amplifiers that run from a single-supply voltage of 2.7 V to 5.5 V.The AD865x family is made up of rail-to-rail input and output amplifiers with a gain bandwidth of 50 MHz and a typical voltage offset of 100 μV across common mode from a 5 V supply. It also features low noise—4.5 nV/√Hz.The AD865x family can be used in communications applications, such as cell phone transmission power control, fiber optic networking, wireless networking, and video line drivers.The AD865x family features the newest generation of DigiTrim® in-package trimming. This new generation measures and corrects the offset over the entire input common-mode range, providing less distortion from VOS variation than is typical of other rail-torail amplifiers. Offset voltage and CMRR are both specified and guaranteed over the entire common-mode range as well as over the extended industrial temperature range.The AD865x family is offered in the narrow 8-lead SOIC package and the 8-lead MSOP package. The amplifiers are specified over the extended industrial temperature range -40°C to +125°C.

Chip1Stop:
OP Amp Single GP R-R I/O 5.5V 8-Pin MSOP Tube

Verical:
Op Amp Single Low Noise Amplifier R-R I/O 5.5V 8-Pin MSOP Tube

Newark:
# ANALOG DEVICES  AD8651ARMZ  Operational Amplifier, Single, 50 MHz, 1, 41 V/ s, 2.7V to 5.5V, MSOP, 8

罗切斯特:
Operational Amplifier, 1700uV Offset-Max, CMOS, PDSO8
