高精度5 V基准 High Precision 5 V Reference
Even in the event of large power supply variations, this voltage reference power management device from Analog Devices can produce and maintain a precise DC voltage. With an output that has a voltage of 5 V, this is power management at its best. It has an initial accuracy of 5mV. The best way to provide power to your application is by using this, which needs a voltage lower than 36 V. To produce a constant current at your output, supply your circuit with a load regulation of 400uV/mA and line regulation of 100uV/V. This voltage reference circuit supports series topology. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This voltage reference circuit has a minimum operating temperature of -40 °C and a maximum of 85 °C. It runs with a maximum temperature coefficient of 15ppm/°C.
容差 ±0.1 %
输入电压DC 36.0V max
输出电压 5 V
输出电流 10 mA
供电电流 3 mA
通道数 1
输入电压Max 36 V
输出电压Max 5 V
输出电压Min 5 V
输出电流Max 10 mA
工作温度Max 85 ℃
工作温度Min -40 ℃
输入电压 10.8V ~ 36V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
高度 1.5 mm
封装 SOIC-8
工作温度 -40℃ ~ 85℃
温度系数 ±15 ppm/℃
产品生命周期 Active
包装方式 Tube
RoHS标准 Non-Compliant
含铅标准 Contains Lead
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
AD586AR ADI 亚德诺 | 当前型号 | 当前型号 |
AD586ARZ 亚德诺 | 完全替代 | AD586AR和AD586ARZ的区别 |
AD586ARZ-REEL 亚德诺 | 完全替代 | AD586AR和AD586ARZ-REEL的区别 |
AD586JRZ-REEL7 亚德诺 | 完全替代 | AD586AR和AD586JRZ-REEL7的区别 |
