AD8561ANZ

Analog Devices### 比较器，Analog Devices

，Analog Devices

得捷:
IC COMPARATOR 1 GEN PUR 8DIP

欧时:
AD8561ANZ 比较器, 互补输出, 5, 9V, 8引脚 PDIP封装

立创商城:
AD8561ANZ

e络盟:
模拟比较器, 单路, 高速, 1个比较器, 7 ns, 2.7V 至 6V, 4.5V 至 5.5V, DIP, 8 引脚

艾睿:
Comparator Single ±5V/10V 8-Pin PDIP N Tube

Jameco:
Comparator Single ±5 Volt 10 Volt 8-Pin PDIP

安富利:
The AD8561 is a single 7 ns comparator with separate input and output sections. Separate supplies enable the input stage to be operated from ±5 V dual supplies and +5 V single supplies.Fast 7 ns propagation delay makes the AD8561 a good choice for timing circuits and line receivers. Propagation delays for rising and falling signals are closely matched and track over temperature. This matched delay makes the AD8561 a good choice for clock recovery, since the duty cycle of the output will match the duty cycle of the input.The AD8561 has the same pinout as the LT1016, with lower supply current and a wider common-mode input range, which includes the negative supply rail.The AD8561 is specified over the industrial -40°C to +85°C temperature range. The AD8561 is available in both the 8-lead plastic DIP, 8-lead TSSOP or narrow SO-8 surface mount packages.

Chip1Stop:
Comparator Single A?A±5V/10V 8-Pin PDIP N Tube

TME:
Comparator; fast; 7ns; 3÷10V; THT; DIP8; Comparators:1; 4uA

Verical:
Comparator Single ±5V/10V 8-Pin PDIP N Tube

Newark:
Analog Comparator, Single, High Speed, 1, 7 ns, 2.7V to 6V, 4.5V to 5.5V, DIP, 8 Pins

罗切斯特:
AD8561 - Comparator, 7000uV Offset-Max, 7ns Response Time, BIPolar, PDIP8

DeviceMart:
IC COMP 7NS ULTRA-FAST 8-DIP

Win Source:
IC COMP 7NS ULTRA-FAST 8-DIP
