2.54mm 圆针
Connector Header Through Hole 26 position 0.100" 2.54mm
得捷:
CONN HEADER VERT 26POS 2.54MM
立创商城:
2.54mm 圆针
艾睿:
Reduce safety concerns with this unshrouded BBS-126-G-B header connector from Samtec which will reduce the possibility of accidentally shorting pins when a printed circuit board is being used. This HDR connector&s;s 26 contacts that are made out of phosphor bronze|brass and plated with gold over nickel. It has a straight body orientation. This is a 1-row connector. Its pitch is 2.54 mm. It has a header type gender. This device has a maximum current rating of 1 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. BBS-126-G-B is housed in black polyester. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 66.04 mm long, 11.69 mm tall and 2.54 mm deep.
安富利:
Conn Unshrouded Header HDR 26 POS 2.54mm Solder ST Thru-Hole Tube
Newark:
# SAMTEC BBS-126-G-B Board-To-Board Connector, 2.54 mm, 26 Contacts, Header, BBS Series, Solder, 1 Rows
