BCS-110-F-D-PE-BE

Conn Socket Strip SKT 20POS 2.54mm Solder ST Thru-Hole Tube

20 Position Receptacle, Pass Through Connector Through Hole

得捷:
CONN RCPT 20POS 0.1 GOLD PCB

艾睿:
Use this socket strip BCS-110-F-D-PE-BE connector from Samtec when board-to-board interconnects is required. This SKT connector&s;s 20 contacts that are made out of phosphor bronze and plated with gold over nickel. It has a socket type gender. This is a 2-row connector. It has a straight body orientation. It has a maximum voltage rating of 475 VAC. Its pitch is 2.54 mm. This device has a maximum current rating of 4.6 A/contact. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. BCS-110-F-D-PE-BE is housed in black liquid crystal polymer. This connector has an operating temperature of -55 to 125 °C. It uses the solder termination method. This product is 25.4 mm long, 7.44 mm tall and 7.62 mm deep.

安富利:
Conn Socket Strip SKT 20 POS 2.54mm Solder ST Thru-Hole Tube
