多层陶瓷电容器, 表面贴装, 33000 pF, 10 V, 0603 [1608 公制], ± 10%, X7R, C系列KEMET
SMD Comm X7R, Ceramic, Commercial Grade, 0.033 uF, 10%, 10 VDC, X7R, SMD, MLCC, Temperature Stable, Class II, 0603
立创商城:
33nF ±10% 10V
得捷:
CAP CER 0.033UF 10V X7R 0603
贸泽:
Multilayer Ceramic Capacitors MLCC - SMD/SMT 10volts 33000pF X7R 10%
e络盟:
多层陶瓷电容器, 表面贴装, 33000 pF, 10 V, 0603 [1608 公制], ± 10%, X7R, C系列KEMET
艾睿:
Due to the use of different ceramic dielectric materials used in this C0603C333K8RACTU multilayer ceramic capacitor from Kemet, you can choose the right capacitor based on capacitance values, voltage ratings, package sizes, and other parameters. It can withstand a voltage of 10 VDC. This MLCC capacitor has a maximum operating temperature of 125 °C. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This product is 1.6 mm long, 0.8 mm tall and 0.8 mm deep. Its capacitance value is 0.033uF. It has a tolerance of 10%.
安富利:
Cap Ceramic 0.033uF 10V X7R 10% SMD 0603 125°C Paper T/R
Verical:
Cap Ceramic 0.033uF 10V X7R 10% Pad SMD 0603 125C T/R
Newark:
# KEMET C0603C333K8RACTU SMD Multilayer Ceramic Capacitor, 0603 [1608 Metric], 0.033 µF, 10 V, ± 10%, X7R, C Series New
额定电压DC 10 V
绝缘电阻 30.303 GΩ
电容 33000 pF
容差 ±10 %
电介质特性 X7R
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 10 V
安装方式 Surface Mount
封装公制 1608
封装 0603
引脚间距 0.7 mm
长度 1.6 mm
宽度 0.8 mm
高度 0.8 mm
封装公制 1608
封装 0603
引脚间距 0.7 mm
介质材料 Ceramic
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 通用
RoHS标准 RoHS Compliant
含铅标准
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
C0603C333K8RACTU KEMET Corporation 基美 | 当前型号 | 当前型号 |
C0603C333K8RAC 基美 | 类似代替 | C0603C333K8RACTU和C0603C333K8RAC的区别 |
C0603C333K1RACTU 基美 | 功能相似 | C0603C333K8RACTU和C0603C333K1RACTU的区别 |
C0603C333K4RACTU 基美 | 功能相似 | C0603C333K8RACTU和C0603C333K4RACTU的区别 |
