0805 4.7uF ±10% 16V X5R
±10% 16V 陶瓷器 X5R 0805（2012 公制）
得捷:
CAP CER 4.7UF 16V X5R 0805
贸泽:
Multilayer Ceramic Capacitors MLCC - SMD/SMT 0805 4.7uF 16volts X5R 10%
艾睿:
Get more with less with TDK&s;s C2012X5R1C475K085AB multilayer ceramic capacitor which uses multiple layers of ceramic and metal to act as dielectric and electrodes. It can withstand a voltage of 16 VDC. This MLCC capacitor has a maximum operating temperature of 85 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. Its capacitance value is 4.7uF. It has a tolerance of 10%. This product is 2 mm long, 0.85 mm tall and 1.25 mm deep.
额定电压DC 16 V
电容 4.7 µF
容差 ±10 %
电介质特性 X5R
工作温度Max 85 ℃
工作温度Min 55 ℃
额定电压 16 V
安装方式 Surface Mount
封装公制 2012
封装 0805
长度 2 mm
宽度 1.2 mm
高度 0.85 mm
封装公制 2012
封装 0805
厚度 0.85 mm
材质 X5R/-55℃~+85℃
介质材料 Ceramic Multilayer
工作温度 -55℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 4000
制造应用 Please refer to Part No., 通用, for Automotive use., Commercial Grade
RoHS标准 RoHS Compliant
含铅标准 Lead Free
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
C2012X5R1C475K085AB TDK 东电化 | 当前型号 | 当前型号 |
C2012X5R1C475M125AC 东电化 | 类似代替 | C2012X5R1C475K085AB和C2012X5R1C475M125AC的区别 |
GRM219R61C475KE15D 村田 | 功能相似 | C2012X5R1C475K085AB和GRM219R61C475KE15D的区别 |
C2012X5R1C475K125AC 东电化 | 功能相似 | C2012X5R1C475K085AB和C2012X5R1C475K125AC的区别 |
