CAT24C16YI-G

CAT24C 系列 16 Kb 2 K X 8 1.8至5.5 V I2C 总线 CMOS 串行 EEPROM - TSSOP-8

The CAT24C16 is a 16-Kb CMOS Serial EEPROM device organized internally as 128 pages of 16 bytes each. This device support both the Standard 100 kHz as well as Fast 400 kHz IData is written by providing a starting address, then loading 1 to 16 contiguous bytes into a Page Write Buffer, and then writing all data to non-volatile memory in one internal write cycle. Data is read by providing a starting address and then shifting out data serially while automatically incrementing the internal address count.External address pins make it possible to address up to one CAT24C16 devices on the same bus.

Features

---

 |

.

Supports Standard and Fast I2C Protocol

.

1.7 V to 5.5 V Supply Voltage Range

.

16-Byte Page Write Buffer

.

Hardware Write Protection for Entire Memory

.

Schmitt Triggers and Noise Suppression Filters on I2C Bus Inputs SCL and SDA

.

Low Power CMOS Technology

.

More than 1,000,000 Program/Erase Cycles

.

RoHS-compliant 8-lead PDIP, SOIC, MSOP and TSSOP, 8-pad TDFN and 5-lead TSOT-23 packages

.

100 Year Data Retention

.

Industrial and Extended Temperature Range
