CLP-102-02-L-D-TR

Conn Socket Strip SKT 4POS 1.27mm Solder ST SMD T/R

The CLP series from are Tiger Claw low profile rugged reliable dual wipe socket strips. These surface mount socket strips mates with Samtec FTSH, FTS and FW series of connectors.

.

Pitch spacing is 1.27mm 2 to 50 contacts per row with double row -D

.

High operating temperature range of -55°C to 125°C

.

Contact material is phosphor bronze

.

Black liquid crystal polymer insulator material

.

Voltage rating is 240VAC/340VDC

.

Complies with UL E111594 standard

.

10µ" gold plated contacts

.

Mating cycles is 100
