DPO3COMP

Tektronix MSO/DPO 3000/4000 Serial Triggering and Analysis Application ModulesSerial triggering and analysis modules enable triggering on packet level information together with analytical tools such as digital views of the signal, bus views, packet decoding, search tools and packet decode tables with time stamp information.### Serial Triggering and AnalysisEmbedded: DPO4EMBD 728-6712 ; DPO3EMBD 727-6667 : Serial Bus l2C, SPl Computer: DPO4COMP 728-6703 ; DPO3COMP 727-6664 : Serial Bus RS-232/422/485/UART Automotive: DPO4AUTO 728-6704 ; DPO3AUTO 727-6655 : Serial Bus CAN, LIN Extended Automotive: DPO4AUTOMAX 728-6709 : Serial Bus CAN, LIN, FlexRay Audio: DPO4AUDIO 727-6695 ; DPO3AUDIO 727-6651 : Serial Bus l2C, LJ, RJ, TDM Aerospace: DPO4AERO 728-6737 : Serial Bus MIL-STD-1553 Ethernet: DPO4ENET 728-6734 : 10BASE-T, 100BASE-TX USB: DPO4USB 728-6715 : USB 2.0 ### Application SupportLimit and Mask Test: DPO4LMT 728-6731 : ITU-T, ANSI-T1.102, USB Standards, Custom User-defined Masks Video: DPO4VID 728-6728 ; DPO3VID 728-6670 : Custom video and HDTV video signals Power Analysis: DPO4PWR 728-6719 ; DPO3PWR 727-6661 : Quality, Current Harmonics, Switching Loss, Safe Operating Area, Slew Rate, Modulation, Ripple ### 混合信号示波器

Computer Serial Triggering and Analysis Module. Enables triggering on packet level information on RS-232/422/485/UART buses as well as analytical tools such as digital views of the signal, bus views, packet decoding, search tools, and packet decode tables with time stamp information.

欧时:
Tektronix MSO/DPO 3000/4000 串行触发和分析应用模块串行触发和分析模块可以结合信号数字视图、总线视图、数据包解码、搜索工具以及带有时间戳信息的数据包解码表等分析工具来触发数据包级别信息。### 串行触发和分析嵌入式：DPO4EMBD 728-6712；DPO3EMBD 727-6667：串行总线 l2C、SPL 计算机：DPO4COMP 728-6703；DPO3COMP 727-6664：串行总线 RS-232/422/485/UART 汽车：DPO4AUTO 728-6704；DPO3AUTO 727-6655：串行总线 CAN、LIN 汽车扩展：DPO4AUTOMAX 728-6709：串行总线 CAN、LIN、FlexRay 音频：DPO4AUDIO 727-6695；DPO3AUDIO 727-6651：串行总线 l2C、LJ、RJ、TDM 航空：DPO4AERO 728-6737：串行总线 MIL-STD-1553 以太网：DPO4ENET 728-6734：10BASE-T、100BASE-TX USB：DPO4USB 728-6715：USB 2.0### 应用支持限制和掩码测试：DPO4LMT 728-6731：ITU-T、ANSI-T1.102、USB 标准、定制用户自定义掩码 视频：DPO4VID 728-6728；DPO3VID 728-6670：自定义视频和 HDTV 视频信号 功率分析：DPO4PWR 728-6719；DPO3PWR 727-6661：质量、电流谐波、切换损耗、安全工作区、转换速率、调制、波纹### 混合信号示波器

e络盟:
示波器模块, 计算机串行触发和分析模块升级, Tektronix MSO/DPO3000系列 示波器, MSO3000 Series

Allied Electronics:
Computer Serial Triggering and AnalysisModule for DPO3000 Series

Newark:
# TEKTRONIX  DPO3COMP  Oscilloscope Module, Computer Serial Triggering & Analysis Upgrade
