ESD 保护器,On Semiconductor
ESD 保护器,On Semiconductor
得捷:
TVS DIODE 3.3VWM 8.4VC 8-UDFN
立创商城:
Vrwm:3.3V@Max
欧时:
ESD 保护二极管 ON Semiconductor ESD8006MUTAG 单向, 8.4V, 10针 U-DFN5515封装
e络盟:
静电保护装置, 8.4 V, UDFN, 8 引脚
艾睿:
Get protected from high voltage shocks with this tvs ESD8006MUTAG ESD protection device developed by ON Semiconductor. This device&s;s maximum clamping voltage is 8.4Typ V. This ESD diode has a maximum ESD protection device voltage of ±15@Air Gap/±15@Contact Disc kV. This ESD diode has a minimum operating temperature of -55 °C and a maximum of 125 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. It is made in a hex common anode configuration.
Allied Electronics:
ESD8006MUTAG, Hex Uni-Directional ESD Protection Diode, 10-Pin UDFN
安富利:
ESD Suppressor Polymer TVS ±15KV 10-Pin UDFN T/R
Verical:
ESD Suppressor Diode TVS Uni-Dir 3.3V Automotive 10-Pin UDFN T/R
Newark:
# ON SEMICONDUCTOR ESD8006MUTAG ESD Protection Device, 8.4 V, UDFN, 8 Pins, 3.3 V
力源芯城:
低电容ESD保护二极管阵列
工作电压 3.3 V
电容 0.32 pF
击穿电压 5.5 V
针脚数 8
钳位电压 8.4 V
测试电流 1 mA
最小反向击穿电压 5.5 V
工作温度Max 125 ℃
工作温度Min -55 ℃
安装方式 Surface Mount
引脚数 8
封装 UDFN-8
长度 3.3 mm
宽度 1 mm
高度 0.5 mm
封装 UDFN-8
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 USB3.0, Thunderbolt, 汽车级
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
