EXB-A10P563J

Res Thick Film NET 56KΩ 5% 200ppm/℃ BUS Molded 10Pin 2512 Concave SMD T/R

56k 欧姆 ±5% 62.5mW 每元件功率 总线式 8 器网络，阵列 ±200ppm/°C 2512（6432 公制），凹陷，长边端子

立创商城:
56kΩ ±5%

得捷:
RES ARRAY 8 RES 56K OHM 2512

艾睿:
Create more space in your circuit design by using this EXB-A10P563J resistor array developed by Panasonic that packs multiple resistors into one IC chip. This dependable part has a power rating per resistor of 0.063 1/16 W. Its temperature coefficient is ±200 ppm/°C. This product&s;s 8 resistors have a value of 56K Ohm. It has 10 terminals. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This product&s;s terminal pitch is 1.27 mm. This product is 6.4 mm long, 0.55 mm tall and 3.1 mm deep. It has a tolerance of 5%. This device is made with thick film technology. This part has an operating temperature of -55 to 125 °C. The EXB-A10P563J part has a concave termination style.

Chip1Stop:
Res Thick Film NET 56K Ohm 5% ±200ppm/C BUS Molded 10-Pin 2512 Concave SMD Embossed Carrier T/R

Verical:
Res Thick Film NET 56K Ohm 5% ±200ppm/C BUS Molded 10-Pin 2512 Concave SMD Automotive T/R

MASTER:
Res Thick Film NET 56K Ohm 5% ±200ppm/°C BUS 10-Pin 2512 Concave SMD Automotive T/R

Online Components:
Res Thick Film NET 56K Ohm 5% ±200ppm/°C BUS Molded 10-Pin 2512 Concave SMD T/R

Electro Sonic:
Res Thick Film NET 56K Ohm 5% ±200ppm/°C BUS 10-Pin 2512 Concave SMD Automotive T/R
