EHF-120-01-F-D

SAMTEC EHF-120-01-F-D Wire-To-Board Connector, 1.27mm, 40Contacts, Header, EHF Series, Through Hole, 2Rows

Connector Header Through Hole 40 position 0.050" 1.27mm

欧时:
1.27mm EHF series PCB ejector header,40P

得捷:
CONN HEADER VERT 40POS 1.27MM

艾睿:
This ejector EHF-120-01-F-D header connector from Samtec reduces the possibility of accidentally shorting pins when a board is being used. This HDR connector&s;s 40 contacts that are made out of phosphor bronze and plated with gold over nickel. This is a 2-row connector. It has a straight body orientation. Its pitch is 1.27 mm. It has a header type gender. This device has a maximum current rating of 1.75 A. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This connector has an operating temperature of -55 to 125 °C. This product is 39.88 mm long, 11.3 mm tall and 6.67 mm deep. EHF-120-01-F-D is housed in black liquid crystal polymer. It uses the solder termination method.

Jameco:
2MM EJECTOR HEADER

安富利:
Conn Ejector Header HDR 40 POS 1.27mm Solder ST Thru-Hole Tube

Verical:
Conn Ejector Header HDR 40 POS 1.27mm Solder ST Thru-Hole Tube

Newark:
# SAMTEC  EHF-120-01-F-D  Wire-To-Board Connector, 1.27 mm, 40 Contacts, Header, EHF Series, Through Hole, 2 Rows
