AC-DC Power Supply Dual-OUT 12V/-12V 0.625A/0.625A 15W 9Pin
封闭式 AC DC 转换器 2 输出 12V -12V - - 625mA，625mA 90 ~ 264 VAC，100 ~ 375 VDC 输入
得捷:
AC/DC CONVERTER +/-12V 15W
艾睿:
With this KMD15-1212 AC to DC power supply from TDK-Lambda your electronic device will be able to operate by using direct current instead of alternating current. It has a voltage of 12|-12 V and maximum output power of 15 W. This part&s;s 2 outputs can handle a current up to 0.625|0.625 A. This part has a minimum operating temperature of -25 °C and a maximum of 70 °C.
Allied Electronics:
Power Supply; AC-DC; 12V@0.625A; -12V@0.625A; 90-264V In; PCB; Medical; KM Series
安富利:
AC/DC Power Supply Dual-OUT 12V/-12V 0.625A/0.625A 15W 9-Pin
Chip1Stop:
AC/DC Power Supply Dual-OUT 12V/-12V 0.625A/0.625A 15W 9-Pin
Verical:
AC/DC Power Supply Dual-OUT 12V/-12V 0.625A/0.625A 15W Medical 9-Pin
Win Source:
AC/DC CONVERTER +/-12V 15W / Enclosed AC DC Converters 2 Output 12V -12V 625mA, 625mA 90 ~ 264 VAC, 100 ~ 375 VDC Input
电源电压DC 264 V
额定功率 15 W
输出接口数 2
输出电压 ±12 V
输出电流 0.625 A
输出功率 15 W
输入电压DC Max 375 V
输入电压DC Min 100 V
输入电压AC Max 264 v
输入电压AC Min 90 v
额定电流Max 0.22 A
输出电流Max 625mA, 625mA
输入电流Min 0.22 A
输出功率Max 15 W
工作温度Max 70 ℃
工作温度Min -25 ℃
电源电压 264 V
电源电压Max 264 V
输入电压 90V ~ 264V
安装方式 Through Hole
引脚数 9
封装 DIP-9
长度 2.52 in
宽度 45.466 mm
高度 23.368 mm
封装 DIP-9
工作温度 -25℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
制造应用 医用型
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/06/16
ECCN代码 EAR99
