TDK LAMBDA KMT40-51515 交流/直流电路板安装电源, 医用, 固定, 5V, 5A, 15V, 500mA, -15V, 500mA
KM Series 15-40W Medical AC-DC PCB-Mount Power Supplies
**Features:**
* Small size and lightweight
* PC Board Mountable
* Wide Range Input
* Medical Safety Certifi cations 4kVAC Input - Output
* Class II No ground needed
* High effi ciency
得捷:
AC/DC CONVERTER 5V +/-15V 40W
艾睿:
AC/DC Power Supply Triple-OUT 5V/15V/-15V 5A/0.5A/0.5A 40W Medical 7-Pin
Allied Electronics:
Power Supply; AC-DC; 5V@5A; 15V@0.5A; -15V@0.5A; 90-264V In; PCB Mnt; Medical; KM Series
Chip1Stop:
AC/DC Power Supply Triple-OUT 5V/15V/-15V 5A/0.5A/0.5A 40W Medical 7-Pin
Verical:
AC/DC Power Supply Triple-OUT 5V/15V/-15V 5A/0.5A/0.5A 40W Medical 7-Pin
Newark:
AC/DC PCB Mount Power Supply PSU, Medical, 3 Output, 40 W, 5 V, 5 A, 15 V, 500 mA
电源电压DC 264 V
额定功率 40.0 W
输出接口数 3
输出电压 5.00 V
输出电流 5.00 A
输出功率 40 W
输入电压DC Max 375 V
输入电压DC Min 100 V
输入电压AC Max 264 v
输入电压AC Min 90 v
输入电流Min 0.86 A
输出功率Max 40 W
工作温度Max 70 ℃
工作温度Min -25 ℃
输入电压 90V ~ 264V
安装方式 Through Hole
引脚数 7
封装 DIP-7
长度 2 in
宽度 63.5 mm
高度 26.924 mm
封装 DIP-7
重量 280.32 g
工作温度 -25℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
制造应用 医用型
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
