LITTELFUSE K1300E70 触发二极管, DIAC / SIDAC, 120 V, 138 V, 10 µA, TO-92, 2 引脚
The is a Standard Bidirectional SIDAC features glass-passivated junctions to ensure a rugged and dependable device capable of withstanding harsh environments. This Teccor® Thyristor is a silicon bilateral voltage triggered switch. Upon application of a voltage exceeding the SIDAC break-over voltage point, the SIDAC switches ON through a negative resistance region to a low ON-state voltage. Conduction continues until the current is interrupted or drops below the minimum holding current of the device.
- .
- AC circuit oriented
触点数 2
额定电流 1.00 A
针脚数 2
正向电压 90.0 V
保持电流 150 mA
保持电流Max 150 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
安装方式 Through Hole
引脚数 2
封装 TO-226-2
封装 TO-226-2
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Bulk
制造应用 Lighting, Power Management, Industrial
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/12/17
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
K1300E70 Littelfuse 力特 | 当前型号 | 当前型号 |
K1300G 力特 | 完全替代 | K1300E70和K1300G的区别 |
K1300E70AP 力特 | 完全替代 | K1300E70和K1300E70AP的区别 |
K1300E70RP2 力特 | 完全替代 | K1300E70和K1300E70RP2的区别 |
