1输出 DIN 导轨和面板安装电源, 24V dc, 50A
**Features:
* **High Quality — Company Wide Failure Rate 29 ppm **
* **Super Small and Compact **
* **Universal Input — 85-264 VAC, 120-370 VDC **
* **Power Factor Correction Complies with EN61000-3-2 Directive **
* **Over-Current Protection **
* **Over-Voltage Protection **
* **Remote On/Off **
* **Alarm Output Voltage Detection **
* **UL, C-UL, TÜV and CE Approvals **
* **RoHS Compliant
得捷:
DIN RAIL POWER SUPPLIES 85-264VA
艾睿:
AC/DC Power Supply Single-OUT 24V 5A 120W
Allied Electronics:
Power Supply; AC-DC; 24V; 5A; 85-264V In; Enclosed; DIN; PFC; Industrial; 120W; KHE Series
Chip1Stop:
AC/DC Power Supply Single-OUT 24V 5A 120W
Verical:
AC/DC Power Supply Single-OUT 24V 5A 120W
CDI:
120W AC-DC Power Supplies Euro Style DIN Rail type,
额定功率 120 W
输出接口数 1
输出电压 24 V
输出电流 5 A
输出功率 120 W
隔离电压 3 kV
输入电压DC Max 370 V
输入电压DC Min 120 V
输入电压AC Max 264 V
输入电压AC Min 85 V
输出电流Max 5 A
输入电流Min 1.2 A
工作温度Max 70 ℃
工作温度Min -25 ℃
输入电压 85V ~ 264V
长度 1.46 in
宽度 4.88 in
高度 133.5 mm
工作温度 -20℃ ~ 70℃
产品生命周期 Active
包装方式 Bulk
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 PB free
ECCN代码 EAR99
