Keylock Switches 4A 125VAC 2A 250VAC Key Pull Pos. 3
is manufactured by and is categorized in the Keylock Switches category. KO130AA126 is described as SWITCH KEYLOCK 3POS SP3T 4A 125V. Perfect Parts is a supplier of Switches and other Electromechanicals.
贸泽:
Keylock Switches 4A 125VAC 2A 250VAC Key Pull Pos. 3
Verical:
Switch Key Lock ON ON SPDT 90° Tubular Key 1A 250VAC Solder Lug Panel Mount
MASTER:
Keylock Switch - SP3T - 3 Position - 4A - 125VAC - Flat Key Actuator - 45° Angle of Throw - Position 3 Is Key Removable - Solder Lug - Panel Mount.
安装方式 Solder Lug, Panel
Series KO
Current-Rating 4A AC
Termination-Style Solder Lug
Mounting-Type Panel Mount
Features -
Circuit SP3T
Voltage-Rating-AC 125V
Voltage-Rating-DC -
Actuator-Type Flat Key
Contact-Material Copper Alloy
Contact-Finish Silver
Number-of-Positions 3
Panel-Cutout-Dimensions Circular - 19.00mm Dia
Switch-Function On-On-On
Contact-Timing Not Specified
Key-Removable-Positions 3 only
Angle-of-Throw 45°
RoHS标准 RoHS Compliant
含铅标准 Lead Free
