KSR211G LFS

1N 或 2N 操作力类型 Gullwing 端子类型。 焊接温度：10 至 15 秒时为 200 至 230°C（红外线回流焊接）；尺寸：高 2.5mm x 宽 7mm x 直径 3.7mm ### 薄型 - 键盘开关

超微型，表面安装

1N 或 2N 操作力类型

Gullwing 端子类型。 焊接温度：10 至 15 秒时为 200 至 230°C（红外线回流焊接）；< 5 秒时为 255°C（双波机器）；< 60 秒时为 215°C（汽相回流焊接）

尺寸：高 2.5mm x 宽 7mm x 直径 3.7mm

欧时:
C & K IP50 按钮式 轻触式开关 KSR211G LFS, 单刀单掷 - 常开, 50 mA @ 32 V 直流 0.75mm 表面安装

e络盟:
轻触开关, KSR Series, 顶部操作, 表面安装, 圆形按钮, 180 gf, 32VDC时, 50mA

艾睿:
This sub-miniature KSR211GLFS tactile switch from C&a;K Components is perfect for turning on your circuit by applying pressure. It has a SPST configuration. This device has a maximum current rating of 0.05. This tactile switch has an operating temperature range of -40 °C to 85 °C. The KSR211GLFS tactile switch has a gull wing termination style. This round button actuator is 0.75 mm long. This product is 7.3 mm long, 2.5 mm tall and 3.8 mm deep. The maximum DC voltage rating is 32 VDC.

TME:
Microswitch TACT; SPST-NO; Positions:2; 0.05A/32VDC; SMT; none

Verical:
Switch Tactile N.O. SPST Round Button Gull Wing 0.05A 32VDC 1VA 100000Cycles 1.8N SMD Automotive T/R

Newark:
# C & K COMPONENTS  KSR211G LFS  SWITCH, SPST, 0.05A, 32VDC, SMD
