Fitting; 1/4in.; 10-32 UNF; UNF; 16.1mm; 1 Mpa; White; -5℃; 60℃; 3.2
* Operating Fluid: Air, Water
* Material: Nickel Plated Brass
* Accepts Nylon and Polyurethane Tubes
* Has Large Retaining Force
* The Use of a Special Profile Ensures Sealing and Reduces Resistance When the Tube Is Inserted
* When the Fitting Is Removed from the Tubing, the Chuck and Collet Are Released, Thus Preventing Them from Biting into the Tube Excessively
* Unique Shape Allows Easy Tube Release
* The Body and Threaded Portion Can Turn Independently
* Standard with Preapplied Thread Sealant
颜色 White
重量 3.2 g
Brand/Series KJ Series
Color White
Diameter, Tube 1⁄4 in.
Length, Overall 16.1 mm
Material, Body Stainless Steel
Material, Gasket Stainless Steel 304, NBR
Operating Fluid Air⁄Water
Pressure, Operating 1 Mpa
Proof Pressure 3 Mpa
Size, Port 10-32 UNF
Size, Thread 10-32 UNF
Size, Tube 1/4 "
Standards UL Listed, CSA Certified
Temperature, Ambient, Maximum 60 °C
Temperature, Ambient, Minimum -5 °C
Thread Type UNF
Type Elbow-Male
Weight 3.2 g
RoHS标准 RoHS Compliant
