Type of meter digital multimeter
Measurement frequency, AC voltage, DC voltage, AC current, DC current, resistance
Kind of display used LCD 3,5 digit 3999
Bargraph 33 segm. 50x/s
Sampling 2,5x/s
DC voltage measuring range 0...340m/3,4/34/340/600V
DC voltage measuring accuracy ±1,5% + 4 digits
AC voltage measuring range 0...3,4/34/340/600V
AC voltage measuring accuracy ±1,5% + 5 digits
DC current measuring range 0,1...60A
DC current measuring accuracy ±2% + 5 digits
AC current measuring range 0,1...60A
AC current measuring accuracy ±2% + 5 digits
Resistance measuring range 0,1...340/3,4/34k/340k/3,4M/34MΩ
Resistance measuring accuracy ±1% + 3 digits 0,1...340kΩ, ±15% + 5 digits 34MΩ, ±5% + 5 digits 3,4MΩ
Frequency measuring range 1...3,4k/10kHz measurement with ACA current clamp, 1...3,4k/34k/340kHz measurement with ACV test leads
Frequency measuring accuracy ±0,1% + 1 digits
Continuity test acoustic signal for R<30Ω
Input impedance for AC voltage 10MΩ/V
Body dimensions 92 x 27 x 128mm
Weight with battery 220g
Power supply 2 batteries 1,5V LR03 AAA
Conform to the norm EN61010 300V CAT III, EN61010 600V CAT II
RoHS标准 RoHS Compliant
含铅标准 Lead Free
