Texas Instruments一系列集成降压(降压)直流-直流控制器,用于需要使用外部电源 MOSFET 来实现完整开关调节器设计的应用。### 直流/直流控制器(外部开关),Texas Instruments
直流/直流降压(降压)控制器(外部开关),Texas Instruments
一系列集成降压(降压)直流-直流控制器,用于需要使用外部电源 MOSFET 来实现完整开关调节器设计的应用。
得捷:
IC REG CTRLR BUCK 14TSSOP
立创商城:
降压型 4.5V~5.5V 2MHz
德州仪器TI:
2.2-V to 16-V, 2-MHz, N-channel FET synchronous buck controller with over and undervoltage latch-off
欧时:
### 直流/直流降压(降压)控制器(外部开关),Texas Instruments一系列集成降压(降压)直流-直流控制器,用于需要使用外部电源 MOSFET 来实现完整开关调节器设计的应用。### 直流/直流控制器(外部开关),Texas Instruments
贸泽:
Switching Controllers N-CH FET Sync Buck Reg Cntlr
艾睿:
Ensure that all of the components within your circuit design receive the proper DC voltage by using Texas Instruments&s; synchronous buck LM2727MTC/NOPB DC voltage controller. With an output that has a voltage of 0.6 to 5 V, this is power management at its best. Its output produces a current of 20 A. This DC voltage controller has single output. This DC voltage controller has an input voltage of 2.2 to 16 V. This part offers a switching frequency of 50 to 2000 kHz in order to work properly. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This DC voltage controller has an operating temperature range of -40 °C to 125 °C.
安富利:
DC DC Cntrlr Single-OUT Sync Buck 2.2V to 16V Input 14-Pin TSSOP Rail
Chip1Stop:
DC DC Cntrlr Single-OUT Sync Buck 2.2V to 16V Input 14-Pin TSSOP Rail
Verical:
DC DC Cntrlr Single-OUT Sync Buck 2.2V to 16V Input 14-Pin TSSOP Tube
DeviceMart:
IC REG CTRLR BUCK PWM VM 14TSSOP
电源电压DC 16.0V max
输出接口数 1
输入电压DC 16.0 V
输出电压 0.6V ~ 5V
输出电流 20 A
通道数 1
静态电流 1.50 mA
阈值电压 4.20 V
调节输出数 1
开关频率 50kHz ~ 2MHz
拓扑结构 Buck
占空比 90 %
输入电压Max 16 V
输入电压Min 2.2 V
最大占空比 0.9
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
输入电压 2.2V ~ 16V
安装方式 Surface Mount
引脚数 14
封装 TSSOP-14
长度 5 mm
宽度 4.4 mm
高度 0.9 mm
封装 TSSOP-14
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM2727MTC/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM2727MTCX/NOPB 德州仪器 | 完全替代 | LM2727MTC/NOPB和LM2727MTCX/NOPB的区别 |
LM2727MTC 德州仪器 | 类似代替 | LM2727MTC/NOPB和LM2727MTC的区别 |
LM2727MTCX 德州仪器 | 类似代替 | LM2727MTC/NOPB和LM2727MTCX的区别 |
