TEXAS INSTRUMENTS LM5025DMTC/NOPB 控制器, PWM, 90V-13V电源, 1 MHz, 3A输出, TSSOP-16
Your circuit will be able to control PWM signals at the inputs using the voltage mode PWM controller, developed by Texas Instruments. It has single PWM output. You can operate this at a switching frequency of 1000Max kHz. In order to ensure parts aren"t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This device has a minimum operating supply voltage of 13 V and a maximum of 90 V. This voltage mode driver"s maximum duty cycle is 80 %. This voltage mode driver has a minimum operating temperature of -40 °C and a maximum of 125 °C.
频率 1 MHz
电源电压DC 13.0V min
输出接口数 2
输出电流 3 A
针脚数 16
上升时间 20 ns
开关频率 200kHz ~ 580kHz
占空比 80 %
最大占空比 80 %
下降时间 15 ns
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压Max 90 V
电源电压Min 13 V
输入电压 13V ~ 90V
安装方式 Surface Mount
引脚数 16
封装 TSSOP-16
封装 TSSOP-16
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tube
制造应用 电源供给, 车用
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
