TAIYO YUDEN LBM2016T150J 电感, 15uH, 190MA, 5%, 20MHZ, SMD
15µH Unshielded Wirewound Inductor 190mA 1.5Ohm 0806 2016 Metric
得捷:
FIXED IND 15UH 190MA 1.5 OHM SMD
立创商城:
15uH ±5% 1.5Ω
e络盟:
电感, 15uH, 190MA, 5%, 20MHZ, SMD
艾睿:
Inductor RF Wirewound 15uH 5% 2.52MHz 25Q-Factor Ferrite 0.19A 1.95Ohm DCR 0806 T/R
Chip1Stop:
Inductor Chip Wirewound 15uH 5% 2.52MHz 25Q-Factor Ferrite 190mA 1.95Ohm DCR 0806 T/R
Verical:
Inductor Chip Wirewound 15uH 5% 2.52MHz 25Q-Factor Ferrite 190mA 1.95Ohm DCR 0806 T/R
Newark:
# TAIYO YUDEN LBM2016T150J Surface Mount High Frequency Inductor, LBM Series, 15 µH, 190 mA, 0806 [2016 Metric], Wirewound
Electro Sonic:
Inductor RF Wirewound 15uH 5% 2.52MHz 25Q-Factor Ferrite 0.19A 1.95Ohm DCR 0806 T/R
额定电流 190 mA
容差 ±5 %
无卤素状态 Halogen Free
电感 15 µH
自谐频率 20 MHz
Q值 25.0
产品系列 LB
屏蔽 No
电感公差 ±5 %
测试频率 2.52 MHz
电阻DC) 1.5 Ω
额定电流DC 190 mA
工作温度Max 105 ℃
工作温度Min -40 ℃
电阻DC Max 1.5 Ω
安装方式 Surface Mount
封装 0806
长度 2.2 mm
宽度 1.8 mm
高度 1.8 mm
封装 0806
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Cut Tape CT
最小包装 2000
RoHS标准 RoHS Compliant
含铅标准 Lead Free
