滑动开关 Slide Switch
Miniature Slide Switch
欧时:
Slide Switch SPST 4A 125V
立创商城:
滑动开关 Slide Switch
贸泽:
Slide Switches SLIDE SWITCH
艾睿:
This L101011MS02Q slide switch from C&a;K Components is the best way to turn your circuit on or off. This device has a maximum current rating of 4 A @ 125VAC 28VDC. It has a SPST configuration. This slide switch has a minimum operating temperature of -30 °C and a maximum of 65 °C. The L101011MS02Q slide switch has a PC pin termination style. This product is 19.1 mm long, 14.18 mm tall and 10.8 mm deep. The maximum AC voltage rating is 250 VAC and the maximum DC voltage rating is 125 VDC.
安富利:
Switch Slide SPST Top Slide 4A 250VAC 125VDC PC Pins Thru-Hole
Chip1Stop:
Switch Slide SPST Top Slide 4A 250VAC 125VDC PC Pins Thru-Hole
Verical:
Switch Slide ON OFF SPST Top Slide 4A 250VAC 125VDC PC Pins Thru-Hole Bulk
Newark:
Switch Slide SPST Top Slide 4A 250VAC 125VDC PC P
MASTER:
Miniature Slide Switch
Online Components:
Miniature Slide Switch
Electro Sonic:
Miniature Slide Switch
额定电流 4.00 A
排数 1
额定电流Max 4A @125VAC, 28VDC
工作温度Max 65 ℃
工作温度Min -30 ℃
额定电压DC Max 125 V
额定电压AC Max 250 V
接触电阻Max <10 mΩ
安装方式 Through Hole
封装 散装
高度 14.18 mm
封装 散装
触点材质 Copper
工作温度 -30℃ ~ 65℃
产品生命周期 10000 Cycles
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8536509050
