TEXAS INSTRUMENTS LM34CAZ/NOPB 温度传感器
Double up your sensor needs by using this temperature and humidity sensor from Texas Instruments. It has an analogvoltage output. This device"s minimum operating supply voltage of 5 V, while its maximum is 30 V. This part has a minimum operating temperature of -40 °C and a maximum of 110 °C.
得捷:
SENSOR ANALOG -40F-230F TO92-3
立创商城:
LM34CAZ/NOPB
德州仪器TI:
±1°F 5V-30V, Analog output temperature sensor with Fahrenheit scale calibration
贸泽:
板上安装温度传感器 PREC FAHRENHEIT TEMP SENSOR
e络盟:
温度传感器
艾睿:
Temp Sensor AnalogVoltage Serial 2-Wire 3-Pin TO-92
安富利:
Temp Sensor Analog Serial 2-Wire 3-Pin TO-92
Chip1Stop:
Temp Sensor AnalogVoltage Serial 2-Wire 3-Pin TO-92
Verical:
Temp Sensor AnalogVoltage Serial 2-Wire 3-Pin TO-92 Bulk
Newark:
# TEXAS INSTRUMENTS LM34CAZ/NOPB Temperature Sensor IC, Voltage, ± 0.4°F, -40 °F, 230 °F, TO-92, 3 Pins
DeviceMart:
IC SENSOR TEMP PREC FAHR TO92-3
电源电压DC 5.00V min
输出电流 10 mA
供电电流 117 µA
针脚数 3
静态电流 75.0 µA
工作温度Max 110 ℃
工作温度Min -40 ℃
精度 ±0.8 %
电源电压 4V ~ 30V
电源电压Max 30 V
电源电压Min 5 V
安装方式 Through Hole
引脚数 3
封装 TO-92-3
封装 TO-92-3
工作温度 -40℃ ~ 110℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM34CAZ/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM34DZ 德州仪器 | 类似代替 | LM34CAZ/NOPB和LM34DZ的区别 |
LM34CZ 美国国家半导体 | 功能相似 | LM34CAZ/NOPB和LM34CZ的区别 |
