TEXAS INSTRUMENTS LM83CIMQAX/NOPB 温度传感器芯片, QSOP, 16 引脚
The is a Digital Temperature Sensor with a 2-wire serial interface that senses the voltage and thus the temperature of three remote diodes using a Delta-Sigma analogue-to-digital converter with a digital over-temperature detector. The device accurately senses its own temperature as well as the temperature of three external devices, such as Pentium II® Processors or diode connected 2N3904s. The temperature of any ASIC can be detected using the LM83 as long as a dedicated diode semiconductor junction is available on the die. Using the SMBus interface a host can access the LM83"s registers at any time. Activation of a T_CRIT_A output occurs when any temperature is greater than a programmable comparator limit, T_CRIT. Activation of an INT output occurs when any temperature is greater than its corresponding programmable comparator HIGH limit. The host can program as well as read back the state of the T_CRIT register and the four T_HIGH registers.
电源电压DC 3.00V min
供电电流 0.8 mA
针脚数 16
静态电流 800 µA
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±4℃ Max
电源电压 3V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 3 V
安装方式 Surface Mount
引脚数 16
封装 QSOP-16
封装 QSOP-16
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 测试与测量, 传感与仪器, 热管理, HVAC, 计算机和计算机周边
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM83CIMQAX/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM83CIMQAX 德州仪器 | 完全替代 | LM83CIMQAX/NOPB和LM83CIMQAX的区别 |
LM83CIMQA/NOPB 德州仪器 | 类似代替 | LM83CIMQAX/NOPB和LM83CIMQA/NOPB的区别 |
LM83CIMQA 德州仪器 | 功能相似 | LM83CIMQAX/NOPB和LM83CIMQA的区别 |
