TEXAS INSTRUMENTS LM71QCIMF/NOPB 芯片, 温度传感器, 14位, ±1.5°C, SOT23-5
温度开关,带集成温度
Texas Instrument 的温度开关系列,带集成,可使用外部电阻器对跳闸温度编程,适用于广泛的应用,如手机、数码相机、无线收发器、PDA、电池管理和热监控。
欧时:
### 温度开关,带集成温度传感器Texas Instrument 的温度开关系列,带集成温度传感器,可使用外部电阻器对跳闸温度编程,适用于广泛的应用,如手机、数码相机、无线收发器、PDA、电池管理和热监控。### 温度和湿度传感器,Texas Instruments
得捷:
SENSOR DIGITAL -40C-150C SOT23-5
立创商城:
LM71QCIMF/NOPB
德州仪器TI:
Automotive Grade, ±1.5°C Temperature Sensor with SPI Interface
贸泽:
板上安装温度传感器 Temperature Sensor
e络盟:
TEXAS INSTRUMENTS LM71QCIMF/NOPB 芯片, 温度传感器, 14位, ±1.5°C, SOT23-5
艾睿:
This LM71QCIMF/NOPB temperature and humidity sensor from Texas Instruments can provide two different sets of data for your processing needs. It has a digital output. This part has a resolution of 13+Sign bit. This device has a minimum operating supply voltage of 2.65 V and a maximum of 5.5 V. This part has a minimum operating temperature of -40 °C and a maximum of 150 °C. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery.
安富利:
Temp Sensor Digital Serial 3-Wire, SPI 5-Pin SOT-23 T/R
Chip1Stop:
Temp Sensor Digital Serial 3-Wire, SPI Automotive 5-Pin SOT-23 T/R
Verical:
Temp Sensor Digital Serial 3-Wire, SPI Automotive 5-Pin SOT-23 T/R
Newark:
# TEXAS INSTRUMENTS LM71QCIMF/NOPB Temperature Sensor IC, Digital, ± 1.5°C, -40 °C, 150 °C, SOT-23, 5 Pins
电源电压DC 2.65V min
供电电流 0.55 mA
针脚数 5
位数 14
静态电流 300 µA
工作温度Max 150 ℃
工作温度Min -40 ℃
精度 ±2℃ Max
电源电压 2.65V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 2.65 V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
长度 3.05 mm
宽度 1.75 mm
高度 1.3 mm
封装 SOT-23-5
工作温度 -40℃ ~ 150℃
产品生命周期 Active
包装方式 Cut Tape CT
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LM71QCIMF/NOPB TI 德州仪器 | 当前型号 | 当前型号 |
LM71QCIMFX/NOPB 德州仪器 | 完全替代 | LM71QCIMF/NOPB和LM71QCIMFX/NOPB的区别 |
LM71CIMF/NOPB 德州仪器 | 类似代替 | LM71QCIMF/NOPB和LM71CIMF/NOPB的区别 |
LM71CIMF 德州仪器 | 类似代替 | LM71QCIMF/NOPB和LM71CIMF的区别 |
