LTC6930CMS8-4.19#PBF

LINEAR TECHNOLOGY  LTC6930CMS8-4.19#PBF  芯片, 振荡器, 32.768KHZ-4.19MHZ, 8MSOP

The is a very low-power precision Silicon Oscillator with a frequency error less than 0.09%. For each oscillator, the user can select one of 8 frequencies between 32.768kHz and 8.192MHz. Based on a fixed master oscillator frequency, internal frequency dividers between 1 and 128 provide the 8 different frequencies. The LTC6930 requires no external components other than power supply bypass capacitors. Requiring only a single 1.7 to 5.5V supply enables operation from a single Li-Ion cell or 2 AA alkaline cells. The LTC6930 features a proprietary control architecture that allows for ultralow power operation while maintaining industry leading accuracy and jitter specifications. The exceptionally fast start-up time, combined with the low power consumption, is ideal for battery operated applications with frequent power-up cycles.

.

No external components to set frequency

.

<0.09% maximum at 25°C Frequency error

.

Start-up time <110µs at all frequencies

.

105µA Typical supply current at 32kHz, V=3V

.

490µA Typical supply current at 8MHz, V=3V

.

<0.15% at V=3V Typical RMS period jitter
